A & F Inline Check Valve 1/4" to 1" NPT (100ILCV)

Image Description Price A & F Inline Check Valve 24 Specifications Type: 1/2" NPT Material: 304 stainless steel Maximum Pressure: 1000 PSI Weight: 1 lb Other Inline Check Valves are on our Inline Check Valve A&F page. $223.16 Add to Cart 24

General Description

Used to prevent backflow in a chemical injection line or small process line

PART #	CONNECTIONS	MATERIAL OF CONSTRUCTION	MAXIMUM PRESSURE	MAXIMUM TEMPERATURE	BACK CHECK	SPRING LOADED
22	1/4" NPT	304 SS	1000 PSI	300 F	316 SS Ball	Yes
24	1/2" NPT	304 SS	1000 PSI	300 F	316 SS Ball	Yes
02-DS	3/8" NPT	304 SS	1000 PSI	300 F	316 SS Ball	Yes
02-DH	3/8" NPT	Polyethylene	100 PSI	100 F	Ceramic Ball	No
002-19-D	1" NPT	304 SS	1000 PSI	300 F	316 SS Ball	Yes
002-22P-D	1" NPT	Polyethylene	100 PSI	100 F	Ceramic Ball	Yes
